Intel® Core™ i5 Fanless Computer
- Intel® Core™ i5-4300U processor
- 1x Mini PCIe expansion
- 2-4x GbE, 4x USB 3.0
- Optional 8-pin Digital I/O
BPC-3060
Description
Specifications
| System | |
| Processor | Intel® Core™ i5-4300U (2.9 GHz, 3M) |
| Chipset | N/A |
| Graphics | Integrated Intel® HD Graphics 4400 |
| Memory | Up to 8GB SO-DIMM DDR3L |
| I/O | |
| Ethernet | 2-4x GbE |
| Video | 2x HDMI 1.4a (Max. 4096 x 2304) |
| USB | 4x USB 3.0 |
| Serial | 1x RS-232 2x RS-232/422/485 |
| Audio | 1x Audio Out 1x Mic In |
| Aux I/O | Optional 8-pin Digital I/O (DB-9 connector) |
| Storage | |
| SATA | 1x Internal SATA for 2.5″ SSD/HDD |
| mSATA | – |
| Expansion | |
| PCI Express | – |
| PCI | – |
| Mini PCIe | 1x half-size mini PCIe socket |
| Power Supply | |
| Input | 9~36V DC |
| Adapter | – |
| Mechanical | |
| Dimensions | 9.37″ (W) x 6.50″ (D) x 2.16″ (H) |
| Weight | 3.81 lbs including SSD and RAM |
| Mounting | Wall Mount |
| Environmental | |
| Operating Temperature | -20°C ~ 60°C |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 60°C at 80% , non-condensing |
| Vibration | Operating, 5 Grms, 5-500 Hz, 3 Axes(w/ SSD, according to IEC60068-2-64) |
| Shock | Operating, 50 Grms, Half-sine 11 ms Duration (w/ SSD, according to IEC60068-2-27) |
| Certifications | CE/FCC Class A |
