Cincoze DE-1000 Intel® Atom™ Quad Core Power Efficiency

Product Highlights:

  • Onboard Intel® Atom™ E3845 Processor Quad Core, 1.91GHz
  • 2x DDR3L SO-DIMM Max. up to 8GB
  • Dual Independent Display from 1x DVI-I and 1x DisplayPort
  • 2x Intel® GbE Port, Support Wake-on-LAN and PXE
  • 1x USB 3.0 and 4x USB 2.0
  • 6x RS232/422/485 Port with 5V/12V Power
  • 4x Isolated DI, 4x Isolated DO
  • 2x 2.5” SATA SSD/HDD Bay
  • 1x mSATA (Shared by Mini-PCIe Socket)
  • 1x CFast Card and 1x SIM Card Socket
  • 9~48VDC Power Input, Support AT/ATX Mode
  • 2x Mini-PCIe Slot for Wi-Fi, GSM, or I/O Expansion
  • Power Ignition Control
  • EN50121-3-2 Certified/ EN62368-1

Cincoze DE-1000 Specifications

System
CPU Intel® Atom™ E3845
Frequency 1.91 GHz
BIOS AMI 64Mbit SPI
Core Number 4
I/O
USB 1x 5Gbps USB 3.2 Gen1, Type A
4x 480Mbps USB 2.0, Type A
COM Port 6x RS-232/422/485
PS/2 1x KB/MS
Expansion
Mini PCI Express 2x Full-size Mini PCIe
Storage
SSD/HDD 2x 2.5" SATA HDD Bay
mSATA 1x mSATA (shared by Mini-PCIe socket)
CompactFlash/CFast 1x CFast
SIM Socket 1
Power Supply
Power Type AT/ATX
Power Supply Voltage 9~48VDC
Mechanical
Dimensions 203 x 200 x 65 mm
Weight 2.84kg
Mounting Wall Mounting (Optional Side / VESA / DIN-Rail Mounting)
Environmental
Operating Temperature Ambient with air flow: -25°C to 70°C (with Industrial Grade Peripherals)
Storage Temperature -30°C to 85°C
Humidity 10%~95% (non-condensing)

View Cincoze DE-1000 Datasheet

Order the DE-1000

A cutting-edge, portable computing option with great performance and adaptability is the Cincoze DE-1000 computer. The DE-1000 is packed with robust processing capabilities and a variety of expansion possibilities, making it suited for a wide range of applications in harsh settings. It was built with industrial-grade durability in mind. Its sturdy design guarantees dependable performance in challenging environments, and its small size makes integration into settings with limited space simple. The Cincoze DE-1000 computer offers remarkable computing power and versatility for demanding industrial and embedded computing demands thanks to cutting-edge features including multiple I/O ports, high-speed networking options, and versatile expansion slots.
