Nuvo-11531 / Nuvo-11588
PRODUCT HIGHLIGHTS
- 212 x 165 x 63 mm low-profile design
- Intel® Core™ Ultra 200 series 35W/ 65W LGA1851 CPU
- Rugged, -25°C to 60°C fanless operation
- Up to 48GB DDR5 6400 memory
- 4x 2.5GbE with optional PoE+ and 4x USB3.2 Gen1 with screw-lock
- 1x M.2 2280 Gen4x4 NVMe and 1x swappable 2.5″ SSD tray for storage
- 1x PCIe Gen4x8 via SlimSAS 8i (SFF-8654) connector (Nuvo-11588 only)
- 8V to 48V wide-range DC input with optional ignition power control
About the Computer
Intel® Core™ Ultra 200 Compact Fanless Computer with 4x PoE+ 2.5GbE, 4x USB 3.2, 1x Easy-Swappable 2.5” SSD Tray, and 1x External SlimSAS Connector
The Nuvo-11531 is one of the most compact fanless embedded AI computers powered by the Intel® Core™ Ultra 200 series. Its low-profile 212 x 165 x 63 mm footprint makes it ideal for constrained spaces, including robotic arms, AMRs, machine vision systems, and roadside cabinets.
Despite its compact size, the Nuvo-11531 does not compromise on performance. Leveraging TSMC’s advanced 3nm process, Intel® Core™ Ultra 200 processors can offer nearly 120% the performance while consuming only 80% of the power*. Furthermore, with the new NPU and integrated GPU, Intel® Core™ Ultra 200 processors deliver up to 36 TOPS, enhancing AI inspection capabilities for existing rule-based computer vision algorithms.
About the Distributor
Industrial PC, Inc.
Industrial PC, Inc. is your US-leader in industrial computing since 1996. We’ll help you find the right solution, provide custom integrations, and deliver your computer(s) ready-to-use upon arrival.
Our US-based support prides itself in communicating with you every step of the way.
Feel free to place your order on this page, or reach out to us any time if you have questions or need assistance making sure you find the right product and configuration.
Coming Soon – Nuvo 11531/11588
Designed for diverse edge applications—such as machine vision, AMRs, and smart automation—the Nuvo-11531 offers versatile sensor connections. It features four PoE+ 2.5GbE ports and four USB 3.2 Gen1 ports for industrial/ security cameras or LiDAR, along with multiple isolated DIO and dual COM ports for communication with external devices. Internally, it includes one M.2 E-key slot for Wi-Fi modules and two mPCIe slots for flexible I/O expansion, supporting 5G/4G modules, COM ports, CAN bus, or additional GbE ports. For data storage, it provides an internal Gen4x4 M.2 NVMe slot for the OS and an easy-swappable 2.5” SSD tray for data logging. The wide DC input and optional ignition power control are ideal for battery-powered applications, such as robotics and in-vehicle usage. Additionally, the Nuvo-11588 variant features a SlimSAS connector with PCIe Gen4x8 bandwidth for external NVMe, U.2 storage, industrial PCIe cameras, or GPUs.
As compact embedded computers, the Nuvo-11531 and Nuvo-11588 deliver exceptional computing performance and extensive I/O connectivity. They are well-suited for various industrial and edge applications, including smart factories, autonomous logistics, smart cities, and robotics—particularly where installation space is limited.
Not ready to order, or not finding your exact configuration? No problem.
Build your custom quote here.
SHIPS FROM INDIANA
3-YEAR WARRANTY
30-DAY TRIAL PERIOD
ASSEMBLED IN THE US
Need help?
Call (888) 255-5508
Nuvo-11531 / Nuvo-11588
Specifications
| System | |
| Processor | Supports Intel® Core™ Ultra 200 CPU (LGA1851 socket, 65W/ 35W TDP) |
| Chipset | Nuvo-11531: Intel® H810 platform controller hub Nuvo-11588: Intel® Q870 platform controller hub |
| Graphics | Integrated Intel Xe Graphics (Up to 64EU) |
| Memory | Up to 48GB DDR5 6400 memory via one SODIMM slot |
| TPM | fTPM 2.0 (standard) / dTPM 2.0 (optional) |
| Panel I/O Interface/td> | |
| Ethernet | 4x 2.5GBASE-T Ethernet ports with screw-lock by Intel® I226 GbE controllers. Port 4 supports Wake-on-LAN (WOL) |
| PoE+ | Optional IEEE 802.3at PoE+ PSE for 4x 2.5GbE ports(100W total power budget) |
| External PCIe Connector | Nuvo-11531: n/a Nuvo-11588: 1x PCIe Gen4x8 via SlimSAS 8i(SFF-8654) connector |
| USB | 4x USB 3.2 Gen1 (5 Gbps) ports with screw-lock 2x USB 2.0 ports |
| Isolated DIO | Nuvo-11531: 4-CH isolated DI and 4-CH isolated DO Nuvo-11588: 8-CH isolated DI and 8-CH isolated DO |
| Video Port | 1x HDMI, supporting 4096 x 2160 resolution 1x DisplayPort, supporting 4096 x 2304 resolution |
| Serial Port | 1x software-programmable RS-232/422/485 ports (COM1) 3x 3-wire RS-232 ports (COM2/ 3/ 4) or 1x RS-422/ 485 port (COM2) |
| Storage Interface | |
| SATA HDD | 1x easy-swappable 2.5″ HDD/ SSD tray for 7mm HDD/ SSD |
| M.2 M | 1x M.2 2280 M key socket (PCIe Gen4x4) for NVMe SSD |
| Internal Expansion Bus | |
| M.2 E | 1x M.2 2230 E key socket for WiFi module |
| Mini PCI Express | 2x full-size mini PCI Express sockets with internal SIM sockets |
| Power Supply | |
| DC Input | 1x 3-pin pluggable terminal block for 8V to 48V DC input with optional ignition power control [1] |
| Mechanical | |
| Dimension | 212 mm (W) x 165 mm (D) x 63 mm (H) |
| Mounting | Wall-mount (standard) or DIN-rail mount (optional) |
| Environmental | |
| Operating Temperature | With 35W CPU -25°C to 60°C [2] With 65W CPU (installation of the optional fan kit is recommended) -25°C to 60°C [2]/[3] |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 10%~90%, non-condensing |
| Vibration | Operating, MIL-STD-810H, Method 514.8, Category 4 |
| Shock | Operating, MIL-STD-810H, Method 516.8, Procedure I |
| Certifications | CE/FCC Class A, according to EN 55032 & EN 55035 |
