Geshem
8-inch MTK 6771 Rugged Tablet

Experience reliable performance in harsh environments with the Geshem 8 Inch MTK 6771 Rugged Tablet.

The Geshem 8 Inch MTK 6771 Rugged Tablet is your adaptable solution for demanding field applications.

Product Highlights:

  • 8″ WXGA (1280 x 800) TFT LCD with high brightness (500/1000 nits) for outdoor visibility.
  • Powerful MTK MT6771 Octa-Core 2.0GHz processor for smooth operation.
  • WiFi 802.11a/b/g/n/ac, Bluetooth 4.0, and LTE for versatile connections.
  • Optional 1D/2D barcode scanner and NFC/RFID streamline data collection.
  • Up to 3 GNSS (GPS/BD/GLonass) for accurate location tracking.
  • Corning Gorilla Glass III with optional AG+AF+Wet Hand/Glove compatibility for use in various conditions.
  • Long-lasting 9800mAh battery for extended work shifts.
  • IP65 (optional IP67) rating and 1.2m drop resistance for demanding environments.
  • User-friendly Android 10.

8 Inch Bright Screen

A bright, scratch-resistant display protected by Corning Gorilla Glass III, a multi-point capacitive touchscreen, and robust construction… these are the features that make the Geshem 8-Inch MTK 6771 Rugged Tablet a top choice for field applications.

Powerful Eight-core Processor

The Geshem 8-Inch MTK 6771 Rugged Tablet offers smooth operation with its powerful eight-core processor and Android 10 OS. 4GB RAM allows for easy multitasking, while 64GB storage provides ample space. This ensures a responsive experience even with demanding field applications.

1P67 High-level Protection

With its IP67 rating, this rugged tablet offers reliable performance in the most challenging conditions. Dust, spills, rain, and even accidental water immersion are no match for its robust design. Whether you’re working in a dusty warehouse, out in the elements, or simply prone to the occasional mishap, this tablet is built to withstand the rigors of your workday.

1D/2D Barcode Scanning

Need to streamline data capture in the field? The Geshem 8-Inch MTK 6771 Rugged Tablet offers an optional 1D/2D barcode scanner for high-speed, accurate barcode reading, even in challenging conditions. Whether you’re managing inventory, tracking assets, or need reliable data input in harsh environments, this scanner delivers.

Geshem 8-inch MTK 6771 Specifications

System Hardware
CPU MTK MT6771 Octa-core 2.0GHz
Memory 4GB
Storage 64GB
Camera 5MP front camera (fixed focus), 13MP rear camera (autofocus, LED light)
Speaker Single speaker, 1.2W/8Ω
MIC Waterproof MIC
Earpiece Waterproof earpiece
Button Power, Volume +/-,
1*Customize function key,
1*Barcode scanner shortcut key
LED Indicator Charging indicator
Sensor Gsensor, Gyroscope, Ecompass, Distance sensor, Motor, Light sensor
Display
LCD Type 8" TFT-LCD
Max. Resolution 1280*800
Luminance 500 cd/m2, Optional 1000 cd/m2
Touchscreen 5-Points projected capacitive, up to 10-points (Optional AG+AF or AG+AF+Wet Hand/Glove)
Cover Glass Corning Gorilla Glass III, hardness 7H, light transmittance 85%
OS
OS Android 10
I/O Interface
POGO PIN 1*POGO PIN (USB+Charging)
USB 1*USB Type C (USB OTG+Charging), 1*USB 2.0, TYPE A
Video 1*mini HD
Audio 3.5mm Headphone Jack
DC Jack 1*DC Jack
SIM Card Slot 1*Micro SIM Card Slot
TF Card Slot 1*TF Card Slot, up to 256GB
Aviation Plug Expansion 1*CAN
Communication
WIFI 802.11a/b/g/n/ac, 2.4G+5.8G Dual-band WIFI
Bluetooth Bluetooth 4.0 (BLE) class1, Transmission range: 10m
GNSS MT6631 GPS+BD+GLonass
WWAN
GSM B2/B3/B5/B8
WCDMA B1/B2/B5/B8
TD-SCDMA B38/B39/B40/B41
CDMA2000 CDMA2000
LTE-FDD B1/B2/B3/B4/B5/B7/B8
LTE-TDD B38/B39/B40/B41
Extended Functions
NFC/RFID Optional NFC/HF-RFID/UHF-RFID (choose one out of three)
Barcode Scanner Optional 1D/2D barcode scanner (choose one out of two)
Power
Power Input 5V DC Input, 5V/3A power adapter (Optional: 5~24V DC power input, no built-in battery)
Battery 9800mAh, 3.8V Li-Ion battery
Battery Life 10 hours (Play 1080P video under LCD 50% backlight)
Environment
Drop Resistance 1.2m free fall to the wooden floor
Operating Temp. -10℃~50℃
Storage Temp. -30℃~70℃
IP Rating Standard IP65, optional IP67
Certificate
Certificate CE, RHOS, UN38.3, MSDS
Mechanical
Dimensions (W x H x D) 256.6 * 145.7 * 22mm (Optional UHF RFID module increases thickness by 9.5mm)
Weight 0.80kg
Color Black
Accessory
Standard Hand strap, Type-C OTG cable, 5V/3A power adapter
Optional Docking, Vehicle bracket, Vehicle charger, Passive touch pen, Type-C data cable, Vehicle charging bracket

Order the Geshem 8-inch MTK 6771 Rugged Tablet

The Geshem 8-Inch MTK 6771 Rugged Tablet is a smart choice for field operations, but choosing Industrial PC as your supplier makes it an even better investment. We offer expert guidance to ensure you select the right configuration for your unique needs. Need data capture capabilities? We’ll integrate the perfect barcode scanner or RFID reader. Our team can also customize the tablet’s software and settings to maximize efficiency within your specific workflows. Plus, Industrial PC provides ongoing technical support, ensuring you get the most out of this powerful and durable industrial computing solution.

Frequently Asked Questions

How Are Geshem Windows Rugged Tablets Different From Ordinary Tablets?

Geshem tablets are built with industrial-grade components and undergo rigorous testing (MIL-STD-810G) to withstand harsh environments. They survive drops, spills, shocks, extreme temperatures, and dust far better than consumer tablets.

Why Would I Choose A Rugged Tablet Over A Regular One

Less Downtime: They’re less likely to break, helping you maintain productivity and avoid costly repairs.
Protect Your Investment: A rugged tablet lasts longer, saving you money in the long run.
Work Anywhere: Use it confidently outdoors, on factory floors, or other challenging locations.

I Need A Windows Rugged Tablet, But How Do I Choose The Right One?

Industrial PC simplifies the process! We offer a diverse range of Geshem Windows rugged tablets with options for different performance needs and budgets. Whether you require a cost-effective solution with a Celeron processor or maximum power with a Core i7, we’ll find the perfect fit.

What Specific Features Make Geshem Tablets Rugged?

Key features include:

  • Shock-resistant materials: Designed to handle impacts and drops.
  • Sealed Construction: Protects against dust and water intrusion.
  • Wide Temperature Tolerance: Functions reliably in freezing conditions and high heat.

How Do I Know Which Geshem Tablet Is Right For Me?

Industrial PC can help! Our experts will assess your specific applications and environment.

We’ll guide you to the ideal Geshem tablet based on factors like:

Software Demands: Do you run resource-intensive programs?
Environmental Conditions: Extreme temperatures or dust exposure?
Budget Considerations: We’ll help you balance performance and cost.

I'm Interested In Geshem Windows Rugged Tablets. What Windows Versions Are Supported?

Industrial PC offers a range of Geshem Windows rugged tablets compatible with various operating systems, including Windows 7, Windows 10, and Windows 10 IoT. Additionally, Windows 10 Pro, Home, and IoT versions are available for specific needs.

How Long Does The Battery Last In Geshem Rugged Tablets?

Geshem rugged tablets are designed to keep up with your workday. Many models offer up to 10 hours of battery life on a single charge. However, actual battery life will depend on how you use the tablet and its specific settings.
