Industrial Fanless PC DX-1300Intel® Arrow Lake-S Core™ Ultra 200S Fanless Computer with 2x 2.5GbE, 8x USB 3.2, Triple Display & Wide Temp Range | ![]() Official DistributorCincoze Authorized PartnerDistributed by Industrial PC, Inc. |
Processor
Intel Core Ultra 200S Series (Arrow Lake-S)
Memory
Up to 96GB DDR5 6400/5600
Storage
2x 2.5" SATA + 1x M.2
Ethernet
2x 2.5GbE
Operating Temp
-20°C to 60°C
Power Input
9–48V DC
| Configure & Quote | Spec Sheet | Ordering & Resources |
About the Cincoze DX-1300
The DX-1300 is a compact industrial computer engineered for high-performance edge computing. Powered by an Intel Arrow Lake-S Core™ Ultra 200S series processor, it supports demanding edge applications, including advanced image processing, AI inference, and data integration across multiple tasks. The DX-1300 series packs exceptional computing performance and a rich feature set into a compact chassis while maintaining industrial-grade ruggedness. It is particularly well-suited for high-performance applications with limited installation space and has earned high acclaim in the manufacturing, in-vehicle, and railway markets.
Measuring only 242 x 173 x 75mm, the compact chassis has a footprint comparable to an 11-inch iPad. This enables flexible deployment in space-constrained environments such as control cabinets, equipment interiors, or in-vehicle systems.
Multiple built-in M.2 B/E key slots offer flexible support for wireless communication modules (5G, GNSS, Wi-Fi, Bluetooth), high-speed storage (NVMe SSD), and high-capacity storage (SATA SSD). It also supports I/O expansion modules, allowing for versatile configurations tailored to specific application needs.
Why Industrial PC, Inc?
👴 Our experience is unmatched. We've been around since 1996 (30 years!)
📲 We're easy to reach. Our owners and decision-makers answer the phone. Not an off-shore call center.
🤷🏻♂️ We don't care how many computers you need. A thousand? Great! Just one? Awesome!
📦 We make it easy. We can help you find the right PC, ship it to you ready-to-go out of the box, and our technical support & 3-year warranty will be here when you need us.
⚙️ Endless options available. We have a wide variety in-stock but can also track down and/or customize whatever you need.
Full Specifications
Cincoze DX-1300 by Cincoze — complete technical specifications
| Processor | Intel Core Ultra 200S Series (Arrow Lake-S), 35W/65W TDP |
| Processor Optionsselect one |
|
| Chipset | Intel W880 |
| Graphics | Integrated Intel Xe LPG Graphics, 3 independent displays |
| NPU (AI) | Up to 36 TOPS total platform (GPU + NPU) |
| TPM | dTPM 2.0 (optional CFM-TPM module) |
| BIOS | AMI BIOS |
| Watchdog Timer | Software programmable, 256 levels |
| Ethernet | 2x 2.5GbE (Intel I226) |
| USB |
|
| Serial Ports | 4x RS-232/422/485 (DB9, auto flow control, 5V/12V) |
| Video Output |
|
| Audio | 1x Line-out, 1x Mic-in (Realtek ALC888) |
| Dimensions | 242.2 x 173 x 75 mm (W x D x H) / 9.5" x 6.8" x 3.0" |
| Weight | 3.59 kg (7.9 lbs) |
| Mounting |
|
| Construction | Extruded aluminum with heavy-duty metal |
| Design | Fanless, cableless, jumper-less, unibody |
| Cooling | 1x external fan connector (4-pin terminal block, smart fan) |
| Buttons | Clear CMOS switch, reset button, 0.2s instant reboot |
| Safety | UL, cUL, CB, IEC/EN 62368-1 |
| Railway | EN 50155:2021, EN 50121-1, EN 50121-3-2 |
| Fire Protection | EN 45545-2 |
| Memory | Up to 96GB SO-DIMM DDR5 6400/5600 (2x SO-DIMM slots), ECC/non-ECC (6400 with Ultra 9/7, 5600 with Ultra 5) |
| 2.5" SATA | 2x 2.5" (SATA 3.0), front-accessible hot-swap bays, RAID 0/1/5/10 |
| M.2 2242 SATA | 1x M.2 2242 B-key (PCIe Gen4 x2 / SATA) |
| M.2 B Key | 1x M.2 B-key 3042/3052 (PCIe Gen3 x2 / USB 3.2 Gen1 / SATA) for 5G / GNSS / storage |
| M.2 E Key | 1x M.2 E-key 2230 (PCIe Gen3 x2 / USB 2.0) for WiFi / Bluetooth |
| SIM Socket | 1x SIM socket |
| CMI/CFM Expansion | 2x high-speed CMI + 1x low-speed CMI for optional I/O modules (LAN, PoE, CAN, DIO, COM); 1x CFM-IGN + 1x CFM-TPM interface |
| DC Input | 9–48V DC, 3-pin terminal block |
| Power Budget | Max consumption 162W (35W CPU) / 273W (65W CPU) |
| Ignition Control | Power ignition sensing with delay management, 12V/24V (optional CFM-IGN module) |
| Remote Control & LED Output | 1x remote power on/off (2-pin terminal block), 1x remote power LED (2-pin terminal block) |
| Protection | Reverse power input protection; over-voltage protection 51–58V; over-current protection 15A |
| Power Button | 1x ATX power button, 1x AT/ATX mode switch |
| CMOS Battery | SuperCap, maintenance-free |
| Operating Temperature |
|
| Storage Temperature | -40°C to 85°C |
| Humidity | 95% @ 60°C, non-condensing |
| Vibration | MIL-STD-810H |
| Shock | MIL-STD-810H |
| MTBF | 332,808 hours (Telcordia SR-332) |
| EMC/EMI | CE, UKCA, FCC, ICES-003 Class A; CISPR 32; EN 50121-3-2; EN 61000-3-2/3-3 |
| ESD | EN/IEC 61000-4-2 (contact 6kV, air 8kV); EN/IEC 61000-4-3/4/5/6/8/11 |
| Supported OS | Windows 11, Windows 10, Ubuntu 24.04 |
Build Your Custom Quote
Let us know any specific requirements (processor, memory, I/O, power, mounting, lead times, etc.) and we'll put together a custom quote for you.
| 30 Years in Business | 3-Year Warranty | US-Based Support |

Cincoze DX-1300 is Ideal for Applications Like:
🏭 Factory AutomationThe DX-1300's high-performance Intel® Core™ Ultra 200S processor, wide temperature range, and versatile I/O make it ideal for demanding automation tasks, including real-time control, machine monitoring, and data acquisition in harsh industrial environments. | 🚛 In-Vehicle ComputingWith MIL-STD-810H shock/vibration compliance, ignition sensing support, and wide DC input, the DX-1300 is well-suited for in-vehicle deployments such as fleet management, mobile surveillance, and railway systems requiring reliable operation under dynamic conditions. | 📹 Machine VisionThe DX-1300 delivers up to 36 TOPS of AI compute, triple independent display, and high-speed LAN/PoE expansion, making it a strong fit for machine vision applications involving image processing, AI inference, and multi-camera integration on the edge. |
Ordering Information
Available configurations and model numbers for the Cincoze DX-1300 series.

DAN BARNETT
DAN BARNETT
Director of Technical Sales
Hard to look at. Easy to get ahold of.
Hard to look at.
Easy to get ahold of.
📲 Or shoot him a text: (463) 317-9987
📲 Or shoot him a text:
(463) 317-9987
Installation & Manual
📖 User ManualComplete installation guide, BIOS configuration, and technical reference. Download Manual → | ⚙️ DriversDownload all required drivers for the Cincoze DX-1300 Get Drivers → |
