Industrial Fanless PC
SB-244-11315U
Intel® 13th-Gen Core™ i3 Fanless Controller with 4x LAN, 4x COM, 2x HDMI, and Wide 10–36V DC Input
Processor
Intel® Core™ i3-1315U (13th Gen, Raptor Lake U)
Memory
Up to 32GB DDR5 4800MHz SO-DIMM
Storage
M.2 NVMe, M.2 SATA, 2.5" SATA (RAID 0/1 supported)
Dimensions
200 x 140 x 55.7 mm
Operating Temp
-20°C to 60°C (with airflow, WT RAM & SSD)
I/O
4x LAN (1x GbE, 3x 2.5GbE), 4x COM, 6x USB, 2x HDMI
| Configure & Quote | Spec Sheet | Ordering & Resources |
About the SB-244-11315U
The SB-244-11315U is one of the most compact fanless embedded computers built on the Intel 14th/13th/12th-Gen platform. Measuring just 212 x 165 x 63 mm, it fits into restricted spaces common in robotic arm and AMR applications. Despite its compact size, it does not compromise on performance. Intel 14th-Gen processors deliver up to 24 cores and 32 threads, nearly doubling the performance of previous 10th or 11th-Gen platforms.
The SB-244-11315U offers rich I/O functions including four 2.5GbE ports and four USB 3.2 Gen1 ports for multiple camera connectivity. A Gen4 x4 M.2 NVMe slot supports the latest SSDs with read/write speeds up to 7,000 MB/s, while a hot-swappable HDD tray allows drive replacement without powering down or dismantling the chassis. Two mini PCIe slots and one M.2 E key slot support WiFi or 5G/4G wireless modules. The system also includes 8x DIO, 4x COM ports, and dual display outputs (VGA + DisplayPort).
Combining excellent computing power, abundant connectivity, and a compact footprint, the SB-244-11315U is the ideal fanless computer for industrial applications where installation space is limited.
Why Industrial PC, Inc?
👴 Our experience is unmatched. We've been around since 1996 (30 years!)
📲 We're easy to reach. Our owners and decision-makers answer the phone. Not an off-shore call center.
🤷🏻♂️ We don't care how many computers you need. A thousand? Great! Just one? Awesome!
📦 We make it easy. We can help you find the right PC, ship it to you ready-to-go out of the box, and our technical support & 3-year warranty will be here when you need us.
⚙️ Endless options available. We have a wide variety in-stock but can also track down and/or customize whatever you need.
Full Specifications
SB-244-11315U by ARBOR — complete technical specifications
| Processor | 13th Generation Intel® Core™ i3-1315U (Raptor Lake U series) |
| Chipset | Integrated in CPU |
| Graphics | Intel® UHD Graphics for 13th Gen Processors |
| TPM | Nuvoton NPCT760AABYX TPM 2.0 chip (Discrete) |
| Type | 1 x 262-pin DDR5 SO-DIMM, 4800 MHz |
| Capacity | Up to 32GB |
| M.2 B Key 2242 Slot | SATA signal (RAID 0/1 support via BIOS) |
| SATA 3.0 | 1 x 2.5" HDD/SSD Drive Bay (RAID 0/1 support via BIOS) |
| M.2 M Key 2280 Slot | PCIe x4 signals (NVMe) |
| LAN | 1 x Intel® I219-LM GbE PHY, 3 x Intel® I226-V 2.5GbE (total 4 x RJ45) |
| Serial Ports | 4 x RS232/422/485 (default RS232, 5-pin phoenix terminal head, auto flow control) |
| USB Ports | 3 x USB 3.2, 3 x USB 2.0 (external); 2 x USB 2.0 (internal pin header) |
| Video Outputs | 2 x HDMI (max 4096 x 2304 @ 60Hz) |
| Audio | 1 x Line-out & Mic-in (ALC888S/897) |
| GPIO | 1 x 8-bit programmable GPIO (3.3V/5V jumper adjustable) |
| SIM Card | 1 x SIM Card socket for 4G/5G module |
| Mini PCIe | 1 x Full-size Mini PCIe slot (PCIe x1 / USB 2.0 signals) |
| M.2 E Key 2230 | PCIe x1 / USB 2.0 signals |
| M.2 B Key 2242/3042/3052 | SATA or 4G/5G cellular module (USB 3.2 signals; shared slot, only one card at a time) |
| Input | 10–36V DC, 2-pin Phoenix connector |
| Protection | Over-voltage and reverse power insertion protection |
| Supported OS | Windows 10/11, Ubuntu 22.04 |
| Construction | Aluminum alloy |
| Mounting | Wall-mount, DIN-rail |
| Dimensions | 200 x 140 x 55.7 mm |
| Weight | 1.8 kg |
| Operating Temperature | -20°C to 60°C (with WT RAM & SSD, ambient with airflow) |
| Storage Temperature | -40°C to 85°C |
| Operating Humidity | 10% to 95% @ 40°C (non-condensing) |
| Vibration | 5–500Hz, 2Grms (operation) |
| Shock | 10G @ 11ms (operation); 30G @ 11ms (non-operation) |
| Compliance | CE, FCC |
Build Your Custom Quote
Let us know any specific requirements (processor, memory, I/O, power, mounting, lead times, etc.) and we'll put together a custom quote for you.
| 30 Years in Business | 3-Year Warranty | US-Based Support |
SB-244-11315U is Ideal for Applications Like:
🏭 Factory AutomationThe SB-244-11315U offers robust serial and LAN connectivity, fanless operation, and wide voltage input, making it ideal for PLC control, data acquisition, and industrial networking in demanding factory environments. | 🚛 In-Vehicle ComputingWith 10–36V DC input, over-voltage and reverse power protection, and rugged construction, the SB-244-11315U is well-suited for mobile and vehicular deployments requiring reliable edge processing and multiple network interfaces. | 📹 Machine VisionHigh-speed LAN, dual HDMI outputs, and powerful 13th Gen Intel® Core™ processing enable the SB-244-11315U to support multi-camera machine vision systems and real-time image analysis in industrial inspection or robotics. |
Ordering Information
Available configurations and model numbers for the SB-244-11315U series.
DAN BARNETT
DAN BARNETT
Director of Technical Sales
Hard to look at. Easy to get ahold of.
Hard to look at.
Easy to get ahold of.
📲 Or shoot him a text: (463) 317-9987
📲 Or shoot him a text:
(463) 317-9987
Installation & Manual
📖 User ManualComplete installation guide, BIOS configuration, and technical reference. Download Manual → |
