Industrial Fanless PC SP-241C-1N30523.8" Fanless Industrial Panel PC with Intel® Core™ i3-N305, 10-36V DC Input, and IP66 Front Panel |  Official DistributorArbor Authorized PartnerDistributed by Industrial PC, Inc. |
Processor
Intel® Core™ i3-N305 (8 cores, up to 3.8GHz)
Memory
Up to 16GB DDR5 4800MHz
Storage
1 x 2.5" SATA, 1 x M.2 2242/2280 (SATA), 1 x M.2 2242/2280 (PCIe x4 NVMe, OEM)
Dimensions
594.3 x 366.6 x 70 mm
Operating Temp
-10°C to 60°C
Display
23.8" FHD (1920x1080), 10-point capacitive touch, IP66 front
| Configure & Quote | Spec Sheet | Ordering & Resources |
About the SP-241C-1N305
The SP-241C-1N305 is a 23.8-inch industrial fanless panel PC powered by the Intel® Core™ i3-N305 processor (Alder Lake-N, 8 cores, up to 3.8GHz). Measuring 594.3 x 366.6 x 70 mm, it features a full HD (1920x1080) TFT LCD with 10-point projective capacitive touch and an IP66-rated aluminum front panel. This platform is designed for factory automation, machine control, and industrial HMI applications where reliability and a large, responsive display are critical.
Connectivity and expansion are extensive, with 2 x 2.5GbE LAN, 3 x serial ports (expandable to 5), 4 x USB (2 x USB 3.2, 2 x USB 2.0), HDMI output, and audio I/O. Storage options include a 2.5" SATA bay, M.2 SATA, and (by OEM request) M.2 PCIe NVMe. The system supports up to 16GB DDR5 memory and offers flexible mounting (panel, wall, VESA). Power input is 10–36V DC via a lockable Phoenix connector, with over-voltage and reverse power protection, and remote on/off support.
With its robust build, wide operating temperature, and versatile I/O, the SP-241C-1N305 is engineered for demanding industrial and embedded use cases.
Why Industrial PC, Inc?
👴 Our experience is unmatched. We've been around since 1996 (30 years!)
📲 We're easy to reach. Our owners and decision-makers answer the phone. Not an off-shore call center.
🤷🏻♂️ We don't care how many computers you need. A thousand? Great! Just one? Awesome!
📦 We make it easy. We can help you find the right PC, ship it to you ready-to-go out of the box, and our technical support & 3-year warranty will be here when you need us.
⚙️ Endless options available. We have a wide variety in-stock but can also track down and/or customize whatever you need.
Full Specifications
SP-241C-1N305 by ARBOR — complete technical specifications
| Processor | Intel® Core™ i3-N305 (8 cores, 6M Cache, up to 3.8GHz) |
| Chipset | Integrated in CPU |
| Graphics | Integrated Intel® UHD Graphics |
| Display Size/Type | 23.8" TFT LCD Panel |
| Max. Resolution | 1920 x 1080 (FHD) |
| Luminance | 250 nits |
| Contrast Ratio | 3000:1 |
| Backlight | LED, 30,000 hrs lifetime |
| Touch Type | 10-point projective capacitive |
| Touch Endurance | 35,000,000 touches |
| View Angle | 178°(H) / 178°(V) |
| M.2 E-key 2230 | 1 slot (PCIe x1/USB 2.0, supports CNVi) |
| GPIO | 1 x 8-bit GPIO (3.3V jumper/5V default, optional) |
| Additional COM (optional) | 2 x RS232 |
| Front Panel | Aluminum alloy |
| Heat Sink | Aluminum alloy |
| Rear Cover | SECC |
| Mounting | Panel mount, Wall mount, VESA-mount (75 x 75 mm) |
| Dimensions (W x H x D) | 594.3 x 366.6 x 70 mm |
| Cutout Size | 581.3 x 353.6 mm |
| Weight | 8.2 kg |
| Ingress Protection | Front panel IP66 |
| Supported OS | Windows 10/11, Ubuntu 22.04 |
| Certification | CE, FCC |
| Memory Slot | 1 x DDR5 SO-DIMM, 4800MHz, up to 16GB |
| M.2 M key 2242/2280 (SATA) | 1 slot |
| M.2 M key 2242/2280 (PCIe x4 NVMe) | 1 slot (OEM Request; disables SATA slots) |
| SATA | 1 x SATA 3.0 (2.5" HDD/SSD drive bay) |
| Serial Ports | 1 x RS232/422/485 (COM1, DB9), 1 x RS232(default)/485(Jumper) (COM2, DB9), 1 x RS232 (COM3, DB9) |
| USB Ports | 2 x USB 3.2, 2 x USB 2.0 |
| LAN | 2 x 2.5 GbE (Intel® i226-V, RJ45) |
| HDMI | 1 x HDMI (max 4096x2160@60Hz) |
| Audio | 1 x Line-out & Mic-in (2-in-1, ALC888S), 2 x 4Ω 3W speakers |
| Remote On-Off | 1 x Remote On/Off Switch |
| Power Input | 10~36V DC, 2-pin Phoenix connector |
| Remote Power | Supported |
| Protection | Over-voltage & reversed power insertion |
| Operating Temperature | -10°C to 60°C (14°F to 140°F, with airflow, WT RAM & SSD) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% @ 40°C (non-condensing) |
| Vibration | 5~500Hz, 2Grms operation |
| Shock | Operation: 10G@11ms; Non-operation: 30G@11ms |
Build Your Custom Quote
Let us know any specific requirements (processor, memory, I/O, power, mounting, lead times, etc.) and we'll put together a custom quote for you.
| 30 Years in Business | 3-Year Warranty | US-Based Support |
SP-241C-1N305 is Ideal for Applications Like:
🏭 Factory AutomationThe SP-241C-1N305 provides robust performance and a large, high-resolution touch display for HMI and control applications. Its fanless design, wide voltage input, and IP66 front panel ensure reliable operation in demanding industrial environments. | 🚛 In-Vehicle ComputingWith support for 10–36V DC input, remote power control, and rugged shock/vibration resistance, the SP-241C-1N305 is well-suited for fleet management, logistics, and other mobile industrial deployments. | 📹 Machine VisionThe integrated Intel® UHD Graphics, multiple high-speed LAN ports, and expansive I/O make the SP-241C-1N305 ideal for machine vision systems requiring fast data acquisition, processing, and display. |
Ordering Information
Available configurations and model numbers for the SP-241C-1N305 series.
DAN BARNETT
DAN BARNETT
Director of Technical Sales
Hard to look at. Easy to get ahold of.
Hard to look at.
Easy to get ahold of.
📲 Or shoot him a text: (463) 317-9987
📲 Or shoot him a text:
(463) 317-9987
Installation & Manual
📖 User ManualComplete installation guide, BIOS configuration, and technical reference. Download Manual → |
