Blade HDD System

Ultra-Compact Intel® Fanless Computer

Intel® Atom™ or Celeron® Processor
Intel® Atom™ E3825/E3845 or Intel® Celeron® J1900 processor.
Ultra-Compact Case
Small, lightweight case for thin client and digital signage applications.
mSATA or 2.5″ SSD Storage
Up to 256GB mSATA SSD storage or 512GB SSD.
Configure & Create Quote

Specifications

System
Processor Intel® Atom™ E3825 (1.33 GHz, 1M) (Blade-HDD +2I385CW) Intel® Celeron® J1900 (2.0 GHz, 2M) (Blade-HDD + 2I385S)
Chipset N/A
Graphics Integrated Intel® Graphics
Memory Up to 4GB SO-DIMM DDR3L (Blade-HDD +2I385CW) 2GB SO-DIMM DDR3L (Blade-HDD + 2I385S)
I/O
Ethernet 2x GbE
PoE+ -
Video 1x VGA (Blade-HDD +2I385CW) 1x HDMI & 1x Mini HDMI (Blade-HDD + 2I385S)
USB 2x USB 2.0 (Blade-HDD +2I385CW) 1x USB 2.0 & 1x USB 3.0(Blade-HDD +2I385S)
Serial 1x RS-232 (Blade-HDD +2I385CW)
Audio -
Aux I/O -
Storage
SATA 1x SATA
mSATA 1x mSATA port
Expansion
PCI Express -
PCI -
Mini PCIe 2x Mini PCIe
Power Supply
Input 9~36V DC
Adapter -
Mechanical
Dimensions 150mm (W) x 80.8mm (D) x 42mm (H)
Weight 470g
Mounting -
Environmental
Operating Temperature -25°C ~ 60°C
Storage Temperature -25°C ~ 60°C
Humidity 5%~95% , non-condensing
Vibration -
Shock -
Certifications CE/FCC Class A
Ordering Information
BLADE-HDD + 2I385CW BLADE-HDD with Intel® Atom™ E3825
BLADE-HDD + 2I385S BLADE-HDD with Intel® Celeron® J1900
