D4007P-MA20
Intel® Socket LGA 1700 (Formerly Alder Lake-S and Raptor Lake-S) 4U Rackmount Computer with 6x PCIe & 1x PCI
- Intel® 12th and 13th Gen Processors up to 125W TDP (Max Turbo Power 125W)
- 3x 2.5GbE, 6x USB 3.2, 2x RS-232/422/485
- 6x PCIe, 1x PCI
- Up to three independent displays – HDMI (up to 4K), DisplayPort (up to 4K), VGA
- Accommodates 4x SATA Drives for RAID 0/1/5/10 Support
- Win 11/10 and Linux support
System | |
CPU | Intel® 12th and 13th Gen Processors up to 125W TDP (Max Turbo Power 125W) Socket LGA 1700 (Formerly Alder Lake-S and Raptor Lake-S) |
Chipset | Q670E |
Expansion | |
PCIe | 2x PCIe 4.0 x16(x16/0 or x8/x8) 2x PCIe 4.0 x4 2x PCIe 3.0 x1 |
PCI | 1x PCI |
M.2 | 1x M.2 E-key, 2230 (USB2.0 and PCIe 3.0 x1 CNVi WiFi) 1x M.2 B-key, 3042/3052 (USB3.2/2.0 and PCIe 3.0 x1 for 5G Cellular) |
Memory | |
Technology | Dual-Channel DDR5-5600 MHz (13th Gen.) Dual-Channel DDR5-4800 MHz (12th Gen.) |
Max. | 128GB |
Socket | 4x UDIMM |
SATA | |
SATA3 | 4x SATA3 (6.0Gb/S) |
RAID | RAID 0/1/5/10 |
M.2 | 1 M.2 M-Key, 2242/2280 (PCIe 4.0 x4 NVMe and SATA) 1 M.2 M-Key, 2242/2280 (PCIe 4.0 x4 NVMe) |
Front I/O | |
USB | 2x USB 2.0 |
Rear I/O | |
VGA | 1x VGA (1920 x 1200 at 60Hz) |
DVI | 1x DVI-D (1920 x 1080 at 60Hz) |
HDMI | 1x HDMI 2.0b (4096 x 2160 at 60Hz) |
DisplayPort | 1x DisplayPort 1.4a (4096 x 2304 at 60Hz) |
Ethernet | 3x 2.5GbE (2x I225-V, 1x I225-LM (iAMT)) |
USB | 6x USB 3.2 Gen 2 (10 Gb/s) |
Serial | 2x RS-232/422/485 |
Audio | 1x Audio Out 1x Audio In 1x Mic In |
Internal I/O | |
USB | 1x USB header for 2x USB 3.2 Gen 1 (5 Gb/s) 1x USB header for 2x USB 2.0 (used for 2x front USB 2.0 ports) |
Serial | 4x RS-232 |
GPIO | 8-bit GPIO |
TPM | Intel fTPM 2.0 (PTT) Trusted Computing Firmware Onboard NUVOTON TPM v2.0 |
Mechanical | |
Dimensions | 19″ (W) x 7″ (H) x 20.8″ (D) |
Mounting | Rack Mount |
Environmental | |
Operating Temperature | 0°C ~ 60°C |
Storage Temperature | -20°C ~ 85°C |
Power Requirements | |
Input PWR | ATX PWR (8 + 24) |
Power On | AT/ATX Supported – AT : Directly PWR on as power input ready – ATX : Press button to PWR on after power input ready |
OS Support | |
Windows | Windows 11 Pro (64-bit) Windows 10 IoT LTSC Enterprise 2019 or 2021 |
Linux | Debian 11.4 Fedora 36-1.5 OpenSUSE 15.4 Ubuntu 22.04 VMWare ESXi 8 OpenBSD 7.1 CentOS 9 |
Operating System | Ubuntu 16.04 LTS, Windows 10 Pro (64-bit) |
---|---|
Processor | Hexa-Core Intel® Core™ i5-8000, Hexa-Core Intel® Core™ i7-8000, Quad-Core Intel® Core™ i3-8000 |
Mounting | Rackmount |
