Industrial Fanless PC
Nuvo-9531
Intel® 14th/13th/12th-Gen Core™ Compact Fanless Computer with 4x 2.5GbE, 4x USB 3.2 & Hot-Swappable Storage
Processor
Intel® 14th/13th/12th-Gen Core™
Memory
Up to 32GB DDR4 3200
Storage
M.2 NVMe + Hot-Swap SATA
Dimensions
212 × 165 × 63 mm
Dual Display
VGA + DisplayPort Output
Ignition Control
Optional Power Control
| Configure & Quote | Spec Sheet | Ordering & Resources |
About the Nuvo-9531
The Nuvo-9531 is one of the most compact fanless embedded computers built on the Intel 14th/13th/12th-Gen platform. Measuring just 212 x 165 x 63 mm, it fits into restricted spaces common in robotic arm and AMR applications. Despite its compact size, it does not compromise on performance. Intel 14th-Gen processors deliver up to 24 cores and 32 threads, nearly doubling the performance of previous 10th or 11th-Gen platforms.
The Nuvo-9531 offers rich I/O functions including four 2.5GbE ports and four USB 3.2 Gen1 ports for multiple camera connectivity. A Gen4 x4 M.2 NVMe slot supports the latest SSDs with read/write speeds up to 7,000 MB/s, while a hot-swappable HDD tray allows drive replacement without powering down or dismantling the chassis. Two mini PCIe slots and one M.2 E key slot support WiFi or 5G/4G wireless modules. The system also includes 8x DIO, 4x COM ports, and dual display outputs (VGA + DisplayPort).
Combining excellent computing power, abundant connectivity, and a compact footprint, the Nuvo-9531 is the ideal fanless computer for industrial applications where installation space is limited.
Why Industrial PC, Inc?
👴 Our experience is unmatched. We've been around since 1996 (30 years!)
📲 We're easy to reach. Our owners and decision-makers answer the phone. Not an off-shore call center.
🤷🏻♂️ We don't care how many computers you need. A thousand? Great! Just one? Awesome!
📦 We make it easy. We can help you find the right PC, ship it to you ready-to-go out of the box, and our technical support & 3-year warranty will be here when you need us.
⚙️ Endless options available. We have a wide variety in-stock but can also track down and/or customize whatever you need.
Full Specifications
Nuvo-9531 by Neousys — complete technical specifications
| Processor | - i9-14900 - i9-14900E - i9-14900TE - i7-14700 - i7-14700E - i7-14700TE - i5-14500 - i5-14500E - i5-14500TE - i3-14100 - i3-14100E - i3-14100TE - i9-13900 - i9-13900E - i9-13900TE - i7-13700 - i7-13700E - i7-13700TE - i5-13500 - i5-13500E - i5-13500TE - i3-13100 - i3-13100E - i3-13100TE - i9-12900 - i9-12900E - i9-12900TE - i7-12700 - i7-12700E - i7-12700TE - i5-12500 - i5-12500E - i5-12500TE - i3-12100 - i3-12100E - i3-12100TE |
| Chipset | Intel® H610E Platform Controller Hub |
| Graphics | Intel® UHD Graphics 770 (32 EU) |
| Memory | Up to 32GB non-ECC DDR4 3200 SDRAM (1x SODIMM) |
| TPM | dTPM 2.0 |
| Input | 8-48V DC via 3-pin terminal block |
| Ignition | Optional ignition power control |
| Ethernet | 4x 2.5GBASE-T (Intel® I226-IT) |
| PoE+ | Optional IEEE 802.3at PoE+ PSE, 100W total across 4 ports |
| Display | 1x VGA (1920×1200) + 1x DisplayPort (4096×2304) |
| USB | 4x USB 3.2 Gen1 (5 Gbps) + 2x USB 2.0 |
| Serial | 1x RS-232/422/485 (configurable) 3x RS-232 (3-wire) or 1x RS-422/485 |
| Audio | 1x 3.5mm combo jack (mic + speaker) |
| Operating Temp | -25°C to 60°C (with 35W CPU) |
| Storage Temp | -40°C to 85°C |
| Humidity | 10-90% RH, non-condensing |
| Vibration | MIL-STD-810G, Method 514.6, Cat 4 |
| Shock | MIL-STD-810G, Method 516.6, Proc I |
| Dimensions | 212 × 165 × 63 mm (8.3 × 6.5 × 2.5 in) |
| Weight | 2.5 kg (5.5 lbs) |
| Mounting | Wall-mount (standard) · DIN-rail (optional) |
| M.2 NVMe | 1x M.2 2280 M-Key (PCIe Gen4 x4) |
| SATA | 1x 2.5" hot-swappable tray (7mm HDD/SSD) |
| Mini PCIe | 2x full-size slots with internal SIM sockets |
Build Your Custom Quote
Let us know any specific requirements (processor, memory, I/O, power, mounting, lead times, etc.) and we'll put together a custom quote for you.
| 30 Years in Business | 3-Year Warranty | US-Based Support |
Nuvo-9531 is Ideal for Applications Like:
🏭 Factory AutomationMachine vision, PLC integration, and real-time process control on the factory floor. | 🚛 In-Vehicle ComputingWide voltage input and vibration resistance for fleet management and mobile workstations. | 📹 Surveillance & SecurityPoE+ powers IP cameras directly. Four Ethernet ports for multi-camera NVR setups. |
Ordering Information
Available configurations and model numbers for the Nuvo-9531 series.
DAN BARNETT
DAN BARNETT
Director of Technical Sales
Hard to look at. Easy to get ahold of.
Hard to look at.
Easy to get ahold of.
📲 Or shoot him a text: (463) 317-9987
📲 Or shoot him a text:
(463) 317-9987
Installation & Manual
🔌 Installation GuideView the Quick Installation Guide for the Nuvo-9531 here View the Guide → | 📖 User ManualComplete installation guide, BIOS configuration, and technical reference. Download Manual → |
Ready to Build Your Nuvo-9531?
Custom-configured and tested before it ships. Talk to an engineer today.
Request a Quote →
