IPC-301
Quad-Core Intel® Celeron® J1900 Fanless Computer with PCI Slot
Intel® Celeron® J1900
Quad-Core Bay Trail J1900 processor.
Quad-Core Bay Trail J1900 processor.
PCI Expansion Slot
Supports one PCI card up to 168mm in length.
Supports one PCI card up to 168mm in length.
Compact Fanless Chassis
Wall mountable fanless chassis with a temperature rating of -10°C to 60°C.
Wall mountable fanless chassis with a temperature rating of -10°C to 60°C.
Wireless Connectivity
Dual gigabit ethernet ports and optional WiFi/Bluetooth connectivity via Mini PCIe card.
Dual gigabit ethernet ports and optional WiFi/Bluetooth connectivity via Mini PCIe card.
Specifications
| System | |
| Processor | |
| Chipset | Intel® Express Chipset |
| Graphics | Integrated Intel® Graphics |
| Memory | 4GB SO-DIMM DDR3 |
| I/O | |
| Ethernet | 2x GbE |
| Video | 1x VGA 1x HDMI |
| USB | 2x USB 3.0 4x USB 2.0 |
| Serial | 4x RS-232 2x RS-232/422/485 |
| Audio | 1x Audio Out |
| Expansion | |
| PCI | 1x PCI (max. length 168mm) |
| Mini PCIe | 2x Mini PCIe |
| Storage | |
| SATA | 1x SATA |
| mSATA | 1x mSATA |
| Power Supply | |
| DC Input | 9~36V DC Input |
| Power Adapter | 12V/5A AC Power Adapter |
| Mechanical | |
| Dimensions | 3.94" (w) x 6.89" (d) x 7.28"(h) |
| Weight | 4.5 lbs |
| Mounting | Wall Mount |
| Environmental | |
| Operating Temperature | -10°C ~ 60°C |
| Storage Temperature | -10°C ~ 60°C |
| Humidity | 0%~95% , non-condensing |
| Vibration | Not Available |
| Shock | Not Available |
| Certifications | CE/FCC |
